GRP LIGHT BARRIERS SYSTEM
MGS SOLITION |
 Statistics Show that most work zone accidents ocur at night.Considering this,Moduler Guidance System (MGS) has been developed to protect the motorist from the glare of oncoming head lights and work zone lighting.
Therefore, MGS effectively guides the motorist into, through and out of the work zone minimizing the effect of work zone activity and equipment on the motorist.MGS also minimizes the intimidation caused by opposing traffic.MGS system provides both channellization and delination of traffic lanes.
These MGS modules are not only lightweight but they are olso portable. They transport and install easily and quickly. They provide exceptionel strength flexibility. It has a tensile strenght to weight ratio many times that of steelyet is flexible enough to withstand repeated impacts. It will not rust,rot,wrap or become britte in temparature extremes and it has sufficient UV duriation and can tolerate heavy snow load.
The MGS system combines an innovative modular product design.
- Paslanmaz,
- Çürümez,
- Bozulmaz,
- UV ışınlarına dayanıklıdır,
- Yağmura karşı dayanıklıdır,
- Ağır kar yağışlarına dayanıklıdır.
|
MODULAR GUIDANCE SYSTEM
The design, material selections and anchoring system fort he MGS system were specified foroptimum performance in the severe construction zone enviroment .Any alteretion or substitution of non – approved components will void the limited warrantyand may create liability exposure.
|
| MECHANICAL ANCHORING SYSTEMS |
| Applications : Permanent |
| Type : Mount |
| Bolt size : m12x80 |
| Drill size : Q 12 mm |
 |
| |
MGS BASE RAIL
Color : White
Widht : 126mm
Length : 700-1300mm
Weigth : 3000 mm or corresponds to length of barrier
Angles : 131 – directional preset (exceeds 25’’ sight cut off angle)
Spacing : 250mm
Anchor Spacing : preset (1000mm)
Application : Temporary – Permanent
* Stated lengths are mominal, actuel lengths compencate for variancesin barrier Wall lengths. |
MGS BLADES
Color : Green or concrete gray (custom colors available , call fort he minimum order requirement)
Width : 126mm
Height : standard 600-1300mm
Bracket : Steel |
|
 |
| |
|
 |
|
|
|
